Honeywell MasterLogic ML50 PLC

Get a Price/Quote

Product Details:

Product Type DIGITAL
Application AUTOMATION
Rated Voltage DC19 V Volt (V)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Honeywell MasterLogic ML50 PLC Product Specifications

Application AUTOMATION
Product Type DIGITAL
Rated Voltage DC19 V Volt (V)

Honeywell MasterLogic ML50 PLC Trade Information

Payment Terms Cash Against Delivery (CAD) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
Main Export Market(s) Western Europe South America Eastern Europe North America Central America Africa Middle East Australia Asia
Main Domestic Market All India

Product Description

Block Type:MLI U sets new standards in Ultimate Performance with its many innovations. IoT(Internet of Things) realizes smart factories, MLI-U series is a â€˜User-Orientedâ€™ controller.

Expandable with existed modules for ML50

Applicable max 2 expansion modules with High speed backplane(for network-positioning modules only)

Applicable upto 10 expansion modules

Max. 352 I/O points

Expansion Input/Output module

Special module and functions - Analog input, Analog output, RTD, Thermocouple, High-speed counter, Positioning (Line drive 2 axes, EtherCAT network 8 axes)

Communication modules - RS-232C, RS-422/485, Ethernet, CANopen (Master/Slave),

Profibus-DP (Master/Slave),EtherNet/IP, RAPIEnet.

Data Acquisition with External memory(SD card)

Easy parameter setup for [General save], [Trigger save], [Event save] without instruction

Able to store the working data into max. 16GBytes

Additional Functions: SD memory format, project file up/download, firmware upgrade

Value added service: FTP Link, Diagnostics info, e-mailing with attached data log file

Dual Port Ethernet:

Ports Ethernet switch support

Cost saving through simple wiring

FTP server support(Data acquisition-Logged data, diagnostics info, emailing)

Web Server:

Monitoring of PLC information and data through web browser (PLC basic info., module info., diagnosis, variables monitoring, special flag monitoring, data log file download from server, firmware/ project file update, etc.)

Time synchronization by setting basic parameters (SNTP: Simple Network Time Protocol)

Email service through commercial email (SMTP: Simple Mail Transfer Protocol)

Built-in Analog Input/Output:

Built-in analog input 4 channels (Voltage/Current, resolution=14bits)

Built-in analog output 4 channels (Voltage/Current, resolution=14bits)

Built-in Position control:

Line drive output positioning function with up to 2Mpps 4-axis.

Parameter set up by Softmaster-PM providing operation data edition, divers monitoring and diagnosis functions.

High â€˜Hâ€™ Performance:Modular Type:With its high-speed processing and system capability, ML50 series offers utmost efficiency for your applications.

60ns/Step processing speed and floating-point arithmetic with on-board CPU

Max. 7 expansion modules, Max. 256 I/O point control: PLC system for Low-to-Mid level applications

Max. 5-Channel Communication with built-in functions and expansion modules

Block Type:

83ns/Step processing speed and floating-point arithmetic with on-board CPU

Max. 10 expansion modules, Max. 384 I/O point control: PLC systems for Low-to-Mid level applications

Max. 5-Channel Communication with built-in functions and expansion modules.

Standard â€˜SUâ€™ Type:

94ns/Step processing speed and floating-point arithmetic with on-board CPU

Max. 7 expansion modules and Max 2 Option Boards, Max. 284 I/O point control: PLC systems for Low-to-Mid level applications

Max. 5-Channel Communication with built-in functions and expansion modules.

Economic â€˜Eâ€™ Type:

240ns/Step processing speed and floating-point arithmetic with on-board CPU

Max. 2 Option Boards, Max. 38 I/O point control: PLC systems for Low level and simple applications

Max. 2-Channel Communication with built-in functions(RS232C, RS485).
